Marine Grade Anti-Corrosion PTZ IR Camera

The KDY-EX-PTZ4030IRW02 is a 4MP Explosion proof PTZ camera with 30X optical zoom and a 4.5-135mm focal length. It features a wiper & IR, offering a Field of View (H: 56.2°~2.6°, V: 33.5°~1.4°, D: 69.1°~3.1°) for superior surveillance in hazardous areas. Marine Grade Anti-Corrosion PTZ IR Camera in stock

Marine Grade Anti-Corrosion PTZ IR Camera

Marine Grade Anti-Corrosion PTZ IR Camera

KDY-EX-PTZ4030IRW02: 4MP explosion proof PTZ camera configured for use in hazardous environments in which safety and surveillance are absolutely critical. Featuring 30X optical zoom, with a focal length of 4.5-135 mm. Excellent image quality clear in long distance monitoring of targets.The advanced wiper & IR system endows it with satisfactory clear vision in harsh conditions, rendering it most suitable for heavy industries, oil & gas facilities, and other high-risk areas {FOV: Horizontal 56.2°~2.6°;Vertical 33.5°~1.4°;Diagonal 69.1°~3.1°}.The KDY-EX-PTZ4030IRW02 is built for ATEX and IECEx-certified hazardous zones, making it explosion-proof enough to warrant reliability through steady and easy surveillance under extreme conditions·An explosion-proof video surveillance camera for industrial applications always stands with rugged designs against rough weather, dust, and volatile environments.As Sensor Control LLC, a leading supplier, offers high-grade explosion-proof surveillance solutions: providing safety and compliance to high-risk industries across the UAE and beyond, do contact us. For anything from premium explosion-proof PTZ cameras to other hazardous area security solutions, Sensor Control is the answer.

DNV Certified Marine

The DNV-certified marine and explosion-proof camera is designed for hazardous environments, ensuring reliable surveillance in extreme conditions. It features rugged construction, high-resolution imaging, and resistance to water, dust, and explosions. Ideal for offshore, marine, and industrial applications, it enhances safety, security, and operational efficiency in critical areas.

Explosion Proof Camera

Explosion proof camera is a specialized surveillance device designed for hazardous environments with flammable gases, dust, or vapors. Built with robust enclosures, it prevents ignition of surrounding explosive atmospheres. These cameras are ATEX, IECEx, or UL-certified, ensuring safety in industries like oil & gas, chemical plants, and mining operations.

Contact Information:

Materia

Stainless Steel 316L

Temp.range min

-40℃

Temp.range max

+60℃

Vibration

(0-100Hz) 0.7g

Video

IP

Operational Areas

Outdoor

Mounting

Wall mounted ,column ,Upside etc

Wiper

IR Wiper /IR

Pan/Tilt

Remote operated

Rotation Vertical

±90°

Rotation

Horizontal 360°

Surface

powder coating or electric polishing

Resolution

2MP ,3MP ,4MP ,5MP ,8MP etc

Zoom

20x ,30x ,44x etc

Image Sensor

1/2.8" Progressive Scan CMOS

Min. illumination

Color: 0.002 lux @ F1.2 (AGC ON),B/W: 0.0002 lux @ F1.2 (AGC ON)

CCTV add-on

Heater ,fan

Functions

Cross-line detection, intrusion alarm, illegal parking, automatic tracking, face detection et

Voltage

AC100V-240V

Weight

21kg

Protection Class

IP68

Certificates

DNV TA/ATEX/CE/FCC

Ex-Mark

Ex II 2G Ex db op is IIC T6 Gb II 2DEx tb op is IIIC T80°C Db IP68 IP66
